Casemaker BC1Modular

New Solution

TThe new BC1 is born from the experience of the semi automatic casemaker produced for many years. What is the main difference between the old one and the new one ? the moduls ! the new machine is born for to be a unique solution that customer could customize from the only vacuum table to the complete machine, adding gluing, folfing, board feeding. Starting from that, the customer can personalize the machine under the budget and needs duting the order. It will be possible for other side, buy the separate units as well like only gluing, only folding and added it to the machine already used in the workshop ! This is a revolutionary way to see the case production that permit to get more performance and high productivity as well on small model. Machine ca be run from a single operator or from 2 people under the configuration and this for a different philosophy of job and performance.

Special Futures

High speed and stability ensures high output
Wide application and size range
Fast and simple changeover
High reliable/versatile non-stop cover feeder
Precise and bubble-free gluing
Viscosity controller guarantees

low glue consumption and improves efficiency;
Brush covered folding bars with corner
tucking fingers make tight and accurate folding ;
Lifting transport eliminates scratch and
saves energy;
Loading of board, cover material and
unloading of finished cases in the same
area, and all machine operations
completely visible to operator, which
saves labour
Fine-tuning can be made on-the-fly for
register control
Loading station opens for easy access to
gluing rollers for fast
changeover/cleanup

Casemaker High Speed

Operations

The front and back boards are hopper fed into the machine and precisely registered by pushers so as to achieve perfect alignment with the cover material; The machine can process flexible spine material fed from a roll or rigid spine fed from the board hopper; Cover material is also hopper loaded continuously without stopping the machine, then transferred to the glue application roller by a precise gripper
cylinder in perfect register; Board and cover are combined in continuous rotary motion in perfect
register for bubble-free gluing; The cases are then transferred to the folding and pressing stations by means of a lifting transport assembly  a balanced reciprocating arm with suction heads, which eliminates scratch on the cover;
In the downward movement of the transport suckers, the cover material extending over the board is folded 90 degree, and then drawn over the board by brush covered folding bars
with corner tucking fingers to ensure tight and accurate folds; The cases are then transported through the final pressing station to a counter
stacker, delivering piles of finished cases
on to a roller conveyor to the operator.

Special Futures

High speed and stability ensures high output
Wide application and size range
Fast and simple changeover
High reliable/versatile non-stop cover feeder
Precise and bubble-free gluing
Viscosity controller guarantees

low glue consumption and improves efficiency;
Brush covered folding bars with corner
tucking fingers make tight and accurate folding ;
Lifting transport eliminates scratch and
saves energy;
Loading of board, cover material and
unloading of finished cases in the same
area, and all machine operations
completely visible to operator, which
saves labour
Fine-tuning can be made on-the-fly for
register control
Loading station opens for easy access to
gluing rollers for fast
changeover/cleanup
